Ahuja ABA-4000 Portable Active Speaker

400Watts Portable Active Speaker

PRICE: ₦480,000.00

Power Output (Bi-AMP)
LF: 350W RMS at 1% THD Class H, HF: 50W RMS at 1% THD Class AB

Output Regulation
≤ 0.5dB, no load to full load at 1kHz

Input Channels
INPUT-1: MIC 20mV/3kΩ balanced, LINE: 775mV/10kΩ balanced, INPUT-2: LINE (Jack) 250mV/20kΩ balanced, RCA: 250mV (L&R)/10kΩ

Frequency Response
50-20,000Hz ±3dB

Crossover Frequency
2.5kHz , Filter Slope 24dB per octave

Signal To Noise Ratio
60dB

Tone Controls
Bass: ±5dB at 100Hz, Treble: ±5dB at 10kHz

Output
(a) Loop through (INPUT-1): 20mV or 775mV (b) Mixed Output (1+2): 775mV/1kΩ

Protections
AC: Fuse 1x5A (T 5A L) DC: Fuse 2x8A (T 8A L)

Power Supply
AC: 220-240V 50/60Hz

AC Power Consumption
500VA

Dimensions
W450 x H690 x D360 mm

Weight
28.10kg

quantity:
1
Add To Inquiry
share:
ITEM NO.: AHU-ABA-5000-1
AVAILABLE.: YES
quantity:
1
Add To Inquiry
share:

Ahuja ABA-4000 Portable Active Speaker

PORTABLE PA ACTIVE SPEAKERS
ABA-4000
325 WATTS
PA Active Speaker
Ahuja ABA-4000 Portable Active Speaker has a built-in Bi-Amplifier for the woofer and HF driver separately, for use in a wide variety of Professional and PA Programmes. Feature packed ABA-4000 is ideal equipment for applications such as in Professional Music and Vocal Performances, Touring PA, Mini-Theatres, Pubs and Bars, Religious Gatherings, Stage Monitors etc.
  • 1×Balanced Mic/Line Input is selectable through a push switch.
  • 1×Line Input can be used for connecting a balanced MONO signal through a jack or an unbalanced STEREO signal source through
  • dual RCA.
  • Switchable balanced output either as a Loop through the output of Input-1 or a mix output of Input-1 and 2.
  • Balanced output to link another ABA-4000 or for recording on a computer, or record player.
  • 2-Way Speaker System: 30.48cm (12”) LF Woofer (Ø6.35cm (2.5”) Voice Coil) + Dynamic Horn (Ø4.44cm (1.75”) Voice Coil).
  • Moulded Cabinet Bi-Amp Speaker System.
Ahuja ABA-4000 Portable Active Speaker
Weight 28.10 kg Dimensions 360 × 450 × 690 mm
