SPECIFICATIONS:
Line Output 1
17.5V DC/3A Max.; -34dBV (20mV)
Line Output 2
17.5V DC/3A Max.; -34dBV (20mV)
Power Output
50W RMS at 2% THD, 90W Max.
Inputs
3×Mic 0.65mV/4.7kΩ, 1×Aux 100mV/470kΩ
Frequency Response
60-14,000Hz (± 3dB)
S/N Ratio
> 60dB
Tone Controls
Bass: -10dB at 100Hz, Treble: -10dB at 10kHz
Preamp Output
200mV/600Ω
Line Output
1V/1kΩ
Send Output
200mV/600Ω
Return Input
200mV/10kΩ
Speaker Output
4Ω, 8Ω, 16Ω, 70V & 100V
Power Requirement
AC: 220-240V, 50/60Hz, DC: 24V (2×12V Car Battery)
Power Consumption
250VA
Protections
AC Fuse 1×3 Amp , DC Fuse 2×10 Amp.
Dimensions
W483 × H110× D325 mm
Weight
10.50kg
HOW IT WORKS:
1. Plug the Central Amplifier into the power source.
2. Connect the Chairman/Delegate Units to the Central Amplifier.
3. Connect the microphone to the Central Amplifier.
4. Adjust the volume and other settings as desired.
5. Begin your conference.
PRODUCT FAQ:
Q: Does the AHUJA CMA-5400 have a digital recorder?
A: Yes, the Central Amplifier has a digital recorder for recording the proceedings and can play back pre-recorded messages.
Q: Is the system AC Mains and 24V DC compatible?
A: Yes, the AHUJA CMA-5400 is compatible with both AC Mains and 24V DC power sources.
Q: Does the system have an adjustable headphone output?
A: Yes, adjustable headphone output is available from each Chairman/Delegate Unit.
